SAP Requirements for production of Predicted Energy Assessments (PEAs) & On Construction Energy Performance Certificates (EPCs)

Since SAP calculations are based upon a desk top exercise and not a site survey, it is critical that the correct information is submitted in order that a calculation can be undertaken.  The following is a suggested list of the information sources and data items required:

Information Sources - in either dwg, pdf or paper format

• Site plan to include orientation of the dwelling(s) ie North Point
• Plans of each storey or floor plans, usually at 1:50 scale
• Elevation drawings of each building type
• Section drawing(s) representative of the dwelling showing storey heights etc
• Written specification describing the construction elements and services as per data items below

Data Items

• Site address and postcode
• Details of principle heating and hot water system to include make and model of boiler, details of heating emitters, hot water cylinder size, system controls
• Details of any secondary heating (if applicable)
• Details of ventilation systems
• Details of the internal and external lighting
• Details of the construction of all different heat loss elements (walls, ground floors and roofs) including thickness and type of insulation used
• Details of the doors and windows to include sizes, type of frame, type and thickness of glazing
• Details of any renewable technologies utilised such as photovoltaics, ground source heat pumps

Click here to download our SAP Checklist which details the information we will require to provide our service.
